It is desired that the new doors and drawers should closely match the two images designs below

========================================

Picture of Current Doors in Bath Room

Door Styles to be ordered

Door Style A Cabinet sections 2 Doors Required

=======================================================================

Cross Section of the Door Styles A

((((((((((((((((((((((((((((((((((( )))))))))))))))))))))))))))))))))))))

Order Detail :

All woods should be the same lumber type and quality.  The doors will be stained but the wood needs to be a semi-strong wood which should be a solid wood since the doors will be opened and closed many times and are all located near the floor bottom of the project and subject to young kids and a dog.

What I would like to order!

3 Doors designed like Style A (full door for cabinets bottom section).

The A Style sizes are:

Quantity 1 at 21 1/4 inch wide and 19 3/8 inch tall.  It will be vertically shorter with Face Frame Hinges hinges on the left 4" from top and 4" from Bottom.

Quantity 1 at 21 5/8 inch wide and 19 3/8 inch tall.  It will be vertically shorter with Face Frame Hinges hinges on the right 4" from top and 4" from Bottom.

Quantity 1 at 21 3/8 inch wide and 19 3/8 inch tall.  It will be vertically shorter with Face Frame Hinges on the the right 4" from top and 4 inches from bottom.

The doors created with Style A should have Face Frame Hinges holes installed per the above instructions. Only drill the 1 3/8" shallow (Not a hole) for the Blum Compact hinge. Do not drill the screw holds. The hinges should be installed 4" from the top down and 4" from the bottom side up.

Tom Gegenheimer (480) 289-0521   Cell

or Email to Tomgeg@tlcg.com

++++++++++++++++++++++++

Everbilt Hinge Manufacture's Information on Hinges that will be used

The information is correct other than 4" from top or bottom ( about 1/5 of the door height).
